Industrial Compression Testing Machines

Get a Price/Quote

MOQ : 1 Piece

Industrial Compression Testing Machines Specification

Dimension (L*W*H)
1000 x 800 x 1650 mm

Display Type
Digital

Frequency
50 Hz

Capacity
2000 kN (200 tons)

Gauge
Pressure gauge included

Power
3 HP

Control Mode
Manual & Automatic

Color
Blue & White

Weight
Approx. 800-1200 kg

Accuracy
1% of indicated load

Power Supply
Electric

Usage & Applications
Testing compressive strength of cement, concrete, bricks, and other building materials

Product Type
Industrial Compression Testing Machine

Load Power
Hydraulic

Speed Range
0.5 to 5 mm/min

Features
High load capacity, robust frame, digital display, precise control

Voltage
415 V

Frame Type
Four Column

Stroke
100 mm

Phase
Three Phase

Automation Grade
Semi-Automatic

Industrial Compression Testing Machines Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
50 Pieces Per Month

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
wooden boxes

Main Domestic Market
All India

About Industrial Compression Testing Machines

We are an acclaimed manufacturer of Industrial Compression Testing Machines for our widely spread clients. They are demanded in different industries for testing the compressive strength as per the requirements of our customers. Premium grade raw material is sourced from our trusted vendors and processed using state-of-the-art machinery for fabricating these machines as per the industrial laid norms and standards. These Industrial Compression Testing Machines are hence applauded by our clients in the form of high rising demands among that of our competitors.

High-Performance Compression Testing Solution

Designed to deliver accurate and repeatable results, this machine suits various industrial and laboratory environments. Its high load capacity of 2000 kN, user-friendly digital display, and precise speed control (0.5 to 5 mm/min) make it indispensable for quality control in construction material testing. Featuring efficient hydraulic load power and a robust four-column design, the machine ensures long-term reliability and operational safety.

Integrated Safety and User-Centric Features

Equipped with overload protection, a pressure relief valve, and a secure power system (3 HP motor, 415 V, three-phase supply), this compression tester prioritizes safety during operation. The semi-automatic, digital interface makes both manual and automatic modes accessible, while spacers and platen sets included enhance adaptability for different specimen sizes. The powder-coated finish and sturdy construction withstand rigorous industrial use.

FAQs of Industrial Compression Testing Machines:

Q: How does the compression testing machine measure the strength of building materials?

A: The machine applies a controlled hydraulic load to the specimen placed between the platens, using a digital pressure gauge up to 2000 kN. The result, captured with 1% accuracy, indicates the maximum compressive strength the material can withstand before failure.

Q: What types of materials can be tested using this compression testing machine?

A: This machine is specifically designed to test the compressive strength of cement, concrete, bricks, and various other building materials, making it suitable for both quality control and research applications in construction and materials laboratories.

Q: When should the calibration certificate be used with the machine?

A: The calibration certificate, included with the machine, should be referenced before initial operation and at regular intervals thereafter to ensure measurement precision and compliance with industry standards.

Q: Where is this compression testing machine typically installed?

A: Due to its stationary design and dimensions (1000 x 800 x 1650 mm), the machine is best suited for laboratories, construction material testing facilities, and research institutes where compressive strength assessment is conducted regularly.

Q: What process is involved in operating the semi-automatic control modes?

A: Users can switch between manual and automatic modes via the digital interface. In automatic control, the test progresses with minimal intervention, while manual mode allows for custom control over loading and speed parameters, from 0.5 to 5 mm/min.

Q: How does the machine ensure safe operation during testing?

A: To safeguard both the operator and the machine, built-in safety features such as overload protection and a pressure relief valve automatically mitigate excessive loads and unexpected pressure spikes during testing.

Q: What are the main benefits of using this compression testing machine?

A: This machine provides precise, efficient, and consistent compressive strength measurements, backed by robust construction, user-friendly digital controls, and comprehensive safety mechanismsensuring reliability for industrial and laboratory testing purposes.
